- Realize wireless monitoring function of solar controller
- Support mobile phone APP, plug and play, simple and convenient to set
- Use high performance, ultra-low power consumption Bluetooth dedicated chip
- Fast communication, strong anti-interference ability
- No need of external power supply
- Communication distance up to 10m
| Cyber-BT | |
| Input voltage | 10~60Vdc |
| Standby power consumption | 0.08W |
| Operation power consumption | 0.09W |
| Communication distance | ≤10m |
| Port baud rate | 9600bps |
| RF output power | 2dBm |
| Frequency range | 2400-2483.5MHz |
| Modulation | GFSK |
| Antenna type and Gain | Integral antenna, 2db |
| Communication | Rs485 to BLE |
| Interface type | RJ11 |
| Dimension | 70*51*24.5mm |
| Weight | 50g |
| Woking temperature | -20~70℃ |
| Protection degree | IP30 |
